The protocol is fairly easy to understand and support circuitry is not complex … so straightforward to implement. Another benefit is that programming via SPI is fairly simple. One benefit from a microcontroller programming standpoint is that most microcontroller families have built-in SPI communication, making it easy to connect with peripherals. Aside from control, SPI can also be used for diagnostic purposes. Or in some cases the controller may reside on the same chip where the control signals are generated. Typically, a motor driver with SPI connectivity will have an SPI port that can be connected to a microcontroller which sends control signals such as PWM signals. With regard to how SPI applies to dc motors, the motors themselves aren’t driven directly via SPI but rather by way of a motor driver.
Evaluation boards for brushless dc motor control such as this one from Microchip feature on-board PWM signal generation and an SPI interface - here in the upper left corner with a horizontal six-pin header. Data transmission is from two to 24 bits, depending on how it is programmed.
#SPI ARDUINO CONTROLLER SERIAL#
It transmits data between microcontrollers and peripheral devices such as sensors, memory cards, and displays, among others.Īt its most basic physical level, it’s a four-wire serial interface with data rates that can vary from a few MHz to upwards of 10 MHz or better in some cases. Serial peripheral interface (SPI) is a commonly used input-output standard for synchronous data transmission.
